Item |
P8 |
|
Pixel Composition(SMD) |
2727 |
|
Pixel Pitch(mm) |
8 |
|
Module Resolution(W×H) |
60×40 |
|
Module Size(mm) |
480×320×16 |
|
Module Weight(kg) |
2 |
|
Module Qty/Cabinet(W×H) |
2×3 |
|
Cabinet Resolution(W×H) |
120×80 |
|
Cabinet Size(mm) |
960×960×92 |
|
Cabinet Area(㎡) |
0.92 |
|
Cabinet Weight(kg/cabinet) |
24.5 |
|
Cabinet Material |
Aluminium |
|
Cabinet Density（dot/m²） |
22500 |
|
IP Rating |
IP66 |
|
White Balance Brightness(nits) |
≥6000 |
|
Color Processor(bit) |
14~16 |
|
Color Temperature(K) |
5000-10000 |
|
Visual Angle(H/V) |
140°/ 120° |
|
Luminous point centre deviation |
＜3% |
|
Luminance uniformity |
≥97% |
|
Chromaticity uniformity |
Within ±0.003 (Cx, Cy) |
|
Contrast Ratio |
≥15000:1 |
|
The Max Power Consumption(W/㎡) |
550 |
|
Average Power Consumption(W/㎡) |
186 |
|
Input Voltage |
AC100~240V |
|
Frequency(Hz) |
50&60 |
|
IC Driving(s) |
1/3 |
|
Refreshing Ratio(Hz) |
3840 or 7680 Hz |
|
Maintenance Method |
Front and Rear |
|
Lifespan(hrs) |
100,000 |
|
Work Temperature/Humidity |
-40℃-80℃/10%RH-98%RH |
|
Storage Temperature/Humidity |
-20℃-60℃/10%RH-98%RH |
