New generation flexible LED curtain
for stage rental and media facade, ultra-light, super transparent, quick installation,
easy to form kinds of irregular shapes of led display for creative visual effect.
Brand:
TuringLED|
Parameters of M1 | P37.5mm |
|
|
Model |
M1 | P37.5 |
|
Pixel Pitch |
37.5 mm |
|
Pixel Configuration |
1 x SMD2727 Gold Wire Nationstar |
|
Panel Size |
300x4800 mm |
|
Panel Resolution |
8x128 pixels |
|
Panel Weight |
4 kg/sq.m |
|
Brightness |
1600 nits |
|
IP Rating(Front/Rear) |
IP65 |
|
Refresh Rate |
1000 Hz |
|
Transparency Rate |
50% |
|
Scan Mode |
Static |
|
Max Power consumption |
280W/sq.m |
|
Color Processing |
12 bit |
|
Viewing Angle(H/V) |
140°/110° |
|
Operating Temperature |
-20~45°C |
|
Main Power Source |
AC 100~240V;50/60Hz |
|
Input Voltage |
7.5V DC |
|
Humidity |
10~90%RH |
|
Life Time |
100,000 Hours |
|
Certification |
CE, RoHS |
|
Note: The data may change accordingly. |
|
